CV8 2.5"

SATA SSD

128GB / 256GB / 512GB

NAND Flash: 3D TLC NAND flash

Interface: SATA 3 (6Gb/s)

Sequential Read: UP to 550 MB/s

Sequential Write: UP to 450 MB/s

Technical
AES-256

AES-256

ESD Safety

ESD Safety

Security Erase

Security Erase

EMI Safety

EMI Safety

S-REMOTE

S-REMOTE

TRIM

TRIM

TCG Opal

TCG Opal

Wear Leveling

Wear Leveling

Temperature Monitoring

Temperature Monitoring

OVP/OCP

OVP/OCP

ELPM

ELPM


傳輸速率快
功耗低
RAIFE最新技術

Interface
SATA 3 6.0Gb/s
Capacity
128 GB / 256 GB / 512 GB
Flash Type
3D TLC
Form Factor
2.5"
Sequential Read Speed (Max.)
550 MB/s
Sequential Write Speed (Max.)
450 MB/s
IOPS 4k Random Read/Write (Max.)
90K/70K IOPS
MTBF
> 3 million hours
DWPD
< 1 (3 yrs)
Power Consumption
Operating Voltage
5V
Dimensions (L x W x H) mm
69.85 x 100.45 x 7
Temperature
0°C to 70°C
Storage Temperature
-40°C to 85°C
Weight (Max.)
10g
Security
E2E Data Protection
LDPC ECC
PLP
FW PLP
Features
LowPower
S.M.A.R.T
Category
Industrial
Model Operation Temperature Part number
CV8-CE128 Standard Temp 3C01110316
CV8-CE256 Standard Temp 3C01120363
CV8-CE512 Standard Temp 3C01140302
