介面
|
SATA 3 6.0Gb/s |
|
容量
|
120 GB / 128 GB / 240 GB / 256 GB / 480 GB / 512 GB / 960 GB / 1024 GB / 1920 GB / 2048 GB |
|
Flash 類型
|
3D TLC |
|
規格尺寸
|
2.5" |
|
循序讀取速度（最高）MB/s
|
550 MB/s |
|
循序寫入速度（最高）MB/s
|
510 MB/s |
|
IOPS 4K隨機讀寫 (最高)
|
65K/75K IOPS |
|
平均故障間隔 (MTBF)
|
> 3 million hours |
|
DWPD
|
> 1 (3 yrs) |
|
耗電量 (最大,W)
|
1W typ. |
|
工作電壓
|
5V |
|
尺寸 (長 x 寬 x 高 ) mm
|
100.45mm x 69.85mm x 7mm |
|
作業溫度
|
-25°C to 85°C / -40°C to 85°C |
|
儲存溫度
|
-40°C to 85°C |
|
重量
|
35g |
|
安全性
|
AES-256 E2E Data Protection LDPC ECC TCG Opal |
|
PLP
|
FW PLP HW PLP |
|
特色
|
LowPower S.M.A.R.T. |
|
DRAM Cache
|
DRAM-less |
|
類別
|
Industrial |
建興儲存科技（SSSTC）
| 型號 | 工作溫度 |
|---|---|
| CVC-CD120 | Extended Temp (-25°C to 85°C) |
| CVC-CD128 | Extended Temp (-25°C to 85°C) |
| CVC-CD128 | Extended Temp (-25°C to 85°C) |
| CVC-CT128 | Industrial Temp (-40°C to 85°C) |
| CVC-CU128P | Extended Temp (-25°C to 85°C) |
| CVC-CV128 | Industrial Temp (-40°C to 85°C) |
| CVC-CV128P | Industrial Temp (-40°C to 85°C) |
| CVC-CD240 | Extended Temp (-25°C to 85°C) |
| CVC-CD256 | Extended Temp (-25°C to 85°C) |
| CVC-CD256 | Extended Temp (-25°C to 85°C) |
| CVC-CT256 | Industrial Temp (-40°C to 85°C) |
| CVC-CU256P | Extended Temp (-25°C to 85°C) |
| CVC-CV256 | Industrial Temp (-40°C to 85°C) |
| CVC-CV256P | Industrial Temp (-40°C to 85°C) |
| CVC-CD480 | Extended Temp (-25°C to 85°C) |
| CVC-CD512 | Extended Temp (-25°C to 85°C) |
| CVC-CD512 | Extended Temp (-25°C to 85°C) |
| CVC-CT512 | Industrial Temp (-40°C to 85°C) |
| CVC-CU512P | Extended Temp (-25°C to 85°C) |
| CVC-CV512 | Industrial Temp (-40°C to 85°C) |
| CVC-CV512P | Industrial Temp (-40°C to 85°C) |
| CVC-CD960 | Extended Temp (-25°C to 85°C) |
| CVC-CD1024 | Extended Temp (-25°C to 85°C) |
| CVC-CD1024 | Extended Temp (-25°C to 85°C) |
| CVC-CT1024 | Industrial Temp (-40°C to 85°C) |
| CVC-CU1024P | Extended Temp (-25°C to 85°C) |
| CVC-CV1024 | Industrial Temp (-40°C to 85°C) |
| CVC-CV1024P | Industrial Temp (-40°C to 85°C) |
| CVC-CD1920 | Extended Temp (-25°C to 85°C) |
| CVC-CD2048 | Extended Temp (-25°C to 85°C) |
| CVC-CD2048 | Extended Temp (-25°C to 85°C) |
| CVC-CU2048P | Extended Temp (-25°C to 85°C) |
| CVC-CV2048 | Industrial Temp (-40°C to 85°C) |
| CVC-CV2048P | Industrial Temp (-40°C to 85°C) |
