介面
|
SATA 3 6.0Gb/s |
|
容量
|
40 GB / 80 GB / 128 GB / 160 GB / 256 GB / 320 GB / 640 GB |
|
Flash 类型
|
3D pSLC(TLC) |
|
规格尺寸
|
2.5" |
|
循序读取速度（最高）MB/s
|
550 MB/s |
|
循序写入速度（最高）MB/s
|
510 MB/s |
|
IOPS 4K随机读写 (最高)K
|
65K/75K IOPS |
|
平均故障间隔 (MTBF)
|
> 3 million hours |
|
DWPD
|
> 1 (3 yrs) |
|
耗电量 (W)
|
1W typ. |
|
工作电压
|
5V |
|
尺寸 (长 x 宽 x 高 ) mm
|
100.45mm x 69.85mm x 7mm |
|
作业温度
|
-25°C to 85°C / -40°C to 85°C |
|
储存温度
|
-40°C to 85°C |
|
重量
|
35g |
|
安全性
|
E2E Data Protection LDPC ECC AES-256 TCG Opal |
|
PLP
|
FW PLP |
|
特色
|
LowPower S.M.A.R.T. |
|
类别
|
Industrial |
| 型号 | 备註 |
|---|---|
| CVC-CU40N | Extended Temp (-25°C to 85°C) |
| CVC-CV40N | Industrial Temp (-40°C to 85°C) |
| CVC-CU80N | Extended Temp (-25°C to 85°C) |
| CVC-CV80N | Industrial Temp (-40°C to 85°C) |
| CVC-CU128N | Extended Temp (-25°C to 85°C) |
| CVC-CV128N | Industrial Temp (-40°C to 85°C) |
| CVC-CU160N | Extended Temp (-25°C to 85°C) |
| CVC-CV160N | Industrial Temp (-40°C to 85°C) |
| CVC-CU256N | Extended Temp (-25°C to 85°C) |
| CVC-CV256N | Industrial Temp (-40°C to 85°C) |
| CVC-CU320N | Extended Temp (-25°C to 85°C) |
| CVC-CV320N | Industrial Temp (-40°C to 85°C) |
| CVC-CU640N | Extended Temp (-25°C to 85°C) |
| CVC-CV640N | Industrial Temp (-40°C to 85°C) |
